Emerson Fisher FIELDVUE DVC6000f User Manual

DVC6000f Digital Valve Controllers
December 2009
4-180
Table 4-85. Block Parameter Index (Continued)
Label Page Numbers
Index
Number
BlockParameter Name
Pressure Diff Status
Pressure Diff
PRESSURE_DIFF
STATUS
VALUE
Transducer
38
38.1
38.2
4-45, 6-12
Pressure Units PRESSURE_UNITS Transducer 90 4-35, 4-63
Private Label Distributor DISTRIBUTOR Resource 42 4-17
Process Value PV
AI 7 4-129, 4-134
AO 7 4-71, 4-72, 4-72, 4-75
PID 7 4-86, 4-87, 4-89
Protection PROTECTION Transducer 87 4-62
Process Value Discrete PV_D
DI 7 4-161, 4-163, 4-166
DO 7 4-150, 4-152, 4-152, 4-154
Process Value Filter Time PV_FTIME
AI 18 4-130, 4-135
DI 16 4-163, 4-167
PID 16 4-85, 4-90
Process Value Scale PV_SCALE
AO 11 4-72, 4-74, 4-76
PID 10 4-89
Process Value State PV_STATE DO 11 4-155
Proximity Active PROX_ACTIVE Transducer 74.5 4-54
Proximity Enable PROX_ENABLE Transducer 75.5 4-57
Push Down To PUSH_DOWN_TO Transducer 84.6 4-37, 4-61
PlantWeb Alert Simulate PWA_SIMULATE Transducer 39 4-40, 4-45
Rate RATE PID 26 4-83, 4-91
Rated Travel RATEDTRAVEL Transducer 83.3 4-37, 4-61
RCAS Timeout SHED_RCAS Resource 26 4-4, 4-14
Readback
READBACK AO 16 4-69, 4-76
Readback Discrete
READBACK_D DO 16 4-149, 4-150, 4-153, 4-155
Recommended Action
RECOMMENDED_ACTION Transducer 71 4-53
Relay Type RELAY_TYPE Transducer 42.5 4-36, 4-36, 4-46
Remote Cascade Input RCAS_IN
AO 28 4-70, 4-72, 4-77
PID 32 4-83, 4-91
Remote Cascade Input Discrete RCAS_IN_D DO 22 4-151, 4-155
Remote Cascade Output RCAS_OUT
AO 28 4-77
PID 35 4-92
Remote Cascade Output Discrete RCAS_OUT_D DO 24 4-156
Remote Out Input ROUT_IN PID 33 4-83, 4-91
Remote Out Output ROUT_OUT PID 36 4-92
Reserved TVL_CAL_RESERVED Transducer 45.4 4-48
Reserved A RESERVED_A Transducer 80 4-60
Reserved AI RESERVED_AI Transducer 81 4-60
Reserved B RESERVED_B Transducer 99 4-63
Reset RESET PID 24 4-83, 4-91
Restart RESTART Resource 16 4-13
ROUT Timeout
SHED_ROUT Resource 27 4-5, 4-14
Seat Type
SEAT_TYPE Transducer 84.1 4-37, 4-61
Selected SELECTED ISEL 21 4-108, 4-110
Select Type SELECT_TYPE ISEL 19 4-104, 4-107, 4-108, 4-110
Self Test Status SELFTEST_STATUS Transducer 78 4-60, 4-153, 4-165
Sensor Active SENSOR_ACTIVE Transducer 74.2 4-54
Sensor Enable SENSOR_ENABLE Transducer 75.2 4-57
Set Fault State SET_FSTATE Resource 29 4-5, 4-15, NO TAG
