DVC6000f Digital Valve Controllers
December 2009
8-4
Parts List
Parts which do not show part numbers are not
orderable as individual parts. In most cases, they are
available in one of the parts kits listed under Parts
Kits.
Note
Parts with footnote numbers shown
are available in parts kits. Also see
footnote information at the bottom of
the page.
Key Description Part Number
Housing
DVC6010f, DVC6020f, DVC6030f, DVC6005f
(see figures 8-2, 8-3, 8-4, and 8-5)
1 Housing
(14)
11 Drive Screw
(14)
(2 req’d)
20 Shield
(14)
52 Vent, plastic
(2)
DVC6010f, DVC6030f, and DVC6005f only
74 Mounting Bracket
DVC6020f Std
(3)
or pipe-away
(7)
, and DVC6005f
(21)
75* O-Ring
(7)
, DVC6020f only
245 Pipe Plug, pl stl
(7)
, DVC6020f Vent-away only
248 Screw, hex head
(21)
(4 req’d), (DVC6005f only)
249 Screw, hex head
(21)
(4 req’d), (DVC6005f only)
250 Spacer
(21)
(4 req’d), (DVC6005f only)
267 Standoff
(21)
(2 req’d), ( (DVC6005f only)
271 Screen
(14)
Common Parts
16* O-ring
(1)
(3 req’d)
23 Cap Screw, hex socket, SST
(2)
(4 req’d)
29 Warning label, for use only with LCIE hazardous area
classifications
33 Mach Screw, pan hd, SST
(2)
(3 req’d)
38 Cap Screw, hex socket, SST
(2,13)
(3 req’d)
43* Cover Assembly (includes cover screws)
Aluminum Construction
Standard 38B9580X012
Extreme temperature option
(fluorosilicone elastomers) 38B9580X032
Stainless Steel Construction
Standard 38B9580X022
Extreme temperature option
(fluorosilicone elastomers) 38B9580X042
48 Nameplate
49 Screw, self tapping (2 req’d)
(13)
63 Lithium grease (not furnished with the instrument)
64 Anti-seize compound (not furnished with the instrument)
Key Description Part Number
65 Lubricant, silicone sealant (not furnished with the instrument)
154 Retaining Ring
(2)
(3 req’d)
237 Module Base Seal
(1)
Module Base
DVC6010f, DVC6020f, DVC6030f, DVC6005f
(see figures 8-2, 8-3, 8-4, 8-5, and 8-6)
2 Module Base
(13)
11 Drive Screw
(13)
(2 req’d)
12 O-ring
(1)
19 Label, Shield Assembly
(13)
61 Pipe Plug, hex socket
(13)
(3 req’d)
236 Screen, for single-acting direct units only
(13)
243 Flame Arrestor Assy
(13)
(3 req’d)
I/P Converter Assembly
DVC6010f, DVC6020f, DVC6030f, DVC6005f
(see figures 8-2, 8-3, 8-4, and 8-5)
23 Cap Screw, hex socket, SST
(2,16)
(4 req’d)
39* O-ring
(1,10)
41 I/P Converter
(10)
169 Shroud
(10,16)
210* Boot, nitrile
(1,10)
(2 req’d) (also see figure 7-4)
231* Seal Screen
(1,8,10)
Relay
DVC6010f, DVC6020f, DVC6030f, DVC6005f
(see figures 8-2, 8-3, 8-4, and 8-5)
24* Relay Assembly, (includes shroud, relay seal, mounting screws)
Standard
Single-acting direct (relay C) 38B5786X132
Double-acting (relay A) 38B5786X052
Single-acting reverse (relay B) 38B5786X092
Low Bleed
Single-acting direct (relay C) 38B5786X152
Double-acting (relay A) 38B5786X072
Single-acting reverse (relay B) 38B5786X112
Extreme Temperature option (fluorosilicone elastomers)
Standard Bleed
Single-acting direct (relay C) 38B5786X142
Double-acting (relay A) 38B5786X032
Single-acting reverse (relay B) 38B5786X102
Low Bleed
Single-acting direct (relay C) 38B5786X162
Double-acting (relay A) 38B5786X082
Single-acting reverse (relay B) 38B5786X122
8
*Recommended spare
1. Available in the Elastomer Spare Parts Kit
2. Available in the Small Hardware Spare Parts Kit
3. Available in the DVC6010f to DVC6020f Conversion Kit
7. Available in the Pipe-Away Bracket Kit
8. Available in the Seal Screen Kit
10. Available in the I/P Converter Kit
13. Available in the Spare Module Base Assembly Kit
14. Available in the Spare Housing Assembly Kit
16. Available in the Spare Shroud Kit
21. Available in the Pipestand/Wall Mounting Kit
