Emerson Fisher Fieldvue DVC6020f

PID Function Block
March 2006
5-95
View Lists
View lists allow the values of a set of parameters to be
accessed at the same time. Views 1 and 2 contain
operating parameters and are defined by the Fieldbus
Foundation. View 3 contains dynamic parameters and
View 4 contains static parameters with configuration
and maintenance information. Views 3 and 4 are
defined by the manufacturer.
Table 5-32. PID Function Block, View 1
Index
Number
Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV
8 SP
9 OUT
18 CAS_IN
38 TRK_IN_D
39 TRK_VAL
45.1 ALARM_SUM.CURRENT
45.2 ALARM_SUM.UNACKNOWLEDGED
45.3 ALARM_SUM.UNREPORTED
45.4 ALARM_SUM.DISABLED
Table 5-33. PID Function Block, View 2
Index
Number
Parameter
1 ST_REV
10 PV_SCALE
11 OUT_SCALE
12.1 GRANT_DENY.GRANT
12.2 GRANT_DENY.DENY
17 BYPASS
21 SP_HI_LIM
22 SP_LO_LIM
28 OUT_HI_LIM
29 OUT_LO_LIM
Table 5-34. PID Function Block, View 3
Index
Number
Parameter
1 ST_REV
5.1 MODE_BLK.TARGET_MODE
5.2 MODE_BLK.ACTUAL_MODE
5.3 MODE_BLK.PERMITTED_MODE
5.4 MODE_BLK.NORMAL_MODE
6 BLOCK_ERR
7 PV
8 SP
9 OUT
15 IN
18 CAS_IN
27 BKCAL_IN
31 BKCAL_OUT
32 RCAS_IN
33 ROUT_IN
35 RCAS_OUT
36 ROUT_OUT
38 TRK_IN_D
39 TRK_VAL
40 FF_VAL
45.1 ALARM_SUM.CURRENT
45.2 ALARM_SUM.UNACKNOWLEDGED
45.3 ALARM_SUM.UNREPORTED
45.4 ALARM_SUM.DISABLED
67 ERROR
68 SP_WORK
71 STRUCTURECONFIG
75 STDDEV
76 CAP_STDDEV
5
