Table 5-47. Output Splitter Function Block Parameter Definitions (Continued)
Label
PARAMETER_NAME
Description
Initial
Value
Range
Block
Mode
RO /
RW
Index
Number
Block Alarm
BLOCK_ALM
24
Data Type: DS-72
The block alarm is used for all configuration, hardware,
connection failure, or system problems in the block. The
cause of the alert is entered in the subcode field.
UNACKNOWLEDGED
24.1 RW N/A
0: Undefined
1: Acknowledged
2: Unacknowledged
ALARM_STATE
24.2 RO N/A
0: Undefined
1: Clear reported
2: Clear not reported
3: Active reported
4: Active not
reported
TIME_STAMP
24.3 RO N/A
SUBCODE
24.4 RO N/A
VALUE
24.5 RO N/A
5
