Parts
March 2006
11-7
Figure 11-1. Type DVC6005f Base Unit (continued)
APPLY LUB, SEALANT
NOTES:
1. APPLY LUBRICANT KEY 65 TO ALL O-RINGS UNLESS OTHERWISE SPECIFIED
49B2361 SHT 3 / DOC
SECTION E-E
SECTION C-C
PIPESTAND MOUNTING
WALL MOUNTING
OUTPUT A
SUPPLY
OUTPUT A
SUPPLY
OUTPUT B
OUTPUT B
11
