Resource Block
March 2006
5-17
Table 5-5. Resource Block Parameter Definitions (Continued)
Label
PARAMETER_NAME
Description
Initial
Value
RangeMode
RO /
RW
Index
Number
Write Alarm
WRITE_ALM
40
Data Type: DS-72
This alarm is generated when Unlocked in the
WRITE_LOCK. parameter is set. This alarm
has a priority of WRITE_PRI. For a
WRITE_ALM to be broadcast to the host the
following conditions must be met:
The feature Reports must be selected
Alert communication with the host must be
setup
In the ALARM_SUM parameter, the disable
bit for Write Alarm must be clear.
WRITE_PRI must be greater than 1.
UNACKNOWLEDGED 40.1 RW ALL
0=Undefined
1=Acknowledged
2=Unacknowledged
0=Undefined
ALARM_STATE 40.2 RO NA
0=Undefined
1=Clear reported
2=Clear not reported
3=Active reported
4=Active not reported
0=Undefined
TIME_STAMP 40.3 RO NA 0
SUBCODE 40.4 RO NA 0
VALUE 40.5 RO NA 0
ITK Version
ITK_VER
41 RO N/A *
Data Type: Unsigned16
Major version of ITK test this device has been
tested to. * Initial value depends on the revision
of the DVC6000f.
Extended Parameters
Private Label Distributor
DISTRIBUTOR
42 RO NA 0x5100
Data Type: Unsigned32
Private label distributor
Device String Array
DEV_STRING
43 Unused extended parameter.
Function Block Options
FB_OPTIONS
44 RO
Bits
0: AO
1: DO
2: AI
3: DI
4: PID
5: ISEL
6: OS
7: MAI
All options
enabled
Data Type: Bit String
0=disabled
1=enabled
Indicates which function block licensing options
are enabled. One bit for each block type that is
supported.
Diag Options
DIAG_OPTIONS
45 RO NA
1=FD Fieldbus
Diagnostics
2=AD Advanced
Diagnostics
3=PD Performance
Diagnostics
*
Data Type: Enum
Indicates which diagnostics licensing options
are enabled. *Initial value depends on the
licensed DVC6000f options.
Misc Options
MISC_OPTIONS
46 RO NA
0: Software
Download
10: Travel Control
Capable
0: 1
10: 1
Data Type: Bit String
0=Disable
1=Enable
Indicates which miscellaneous licensing
options are enabled.
Software Revision
SOFTWARE_REVISION
47
Data Type: Uint8
Describes software revision information. This is
the revision of the firmware that is currently in
use.
*Initial value depends on revision of DVC6000f.
SOFTWARE_REV_MAJOR 47.1 RO NA 0−255 *
SOFTWARE_REV_MINOR 47.2 RO NA 0−255 *
SOFTWARE_REV_BUILD 47.3 RO NA 0−255 *
IO_SOFTWARE_REV 47.4 RO NA 0−255 *
DIAG_CAL_REV 47.5 RO NA 0−255 *
SOFTWARE_REV_ALL 47.6 RO NA XX.XX.XX.XX.XX *
Data Type: Visible String
Describes software revision information.
*Initial value depends on revision of DVC6000f.
The range of this parameter consists of 47.1
through 47.5 values, converted to text, and
linked together.
Hardware Revision
HARDWARE_REV
48 RO NA
Hardware revision
number
Factory Set
Data Type: Uint8
Describe electronic hardware revision
information.
Electronics Serial Number
ELECTRONICS_SN
49 RO NA NA Factory Set
Data Type: Visible String
Electronics serial number set by
manufacturing.
−Continued−
