DVC6000f Series
March 2006
5-16
Table 5-5. Resource Block Parameter Definitions (Continued)
Label
PARAMETER_NAME
Description
Initial
Value
RangeMode
RO /
RW
Index
Number
Confirm Time
CONFIRM_TIME
33 RW ALL
> 0
Set by FCS
640000
Data Type: Unsigned32
The time (in 1/32 millisecond) the device waits
for confirmation of receipt of an alert report
before trying again.
Write Lock
WRITE_LOCK
34 RW ALL
0=Undefined
1=Unlocked
2=Locked
1=Unlocked
Data Type: Unsigned8
If set to Locked, no writes from anywhere are
allowed except to clear WRITE_LOCK by
entering Unlocked. Block inputs will continue to
be updated if they are subscribers. The feature
Soft Write Lock must be selected to enable
writing to this parameter (see Device Features
in this section).
Update Event
UPDATE_EVT
35
UNACKNOWLEDGED 35.1 RW ALL
0=Undefined
1=Acknowledged
2=Unacknowledged
0=Undefined
Data Type: DS-73
This alert is generated by any change to the
static data. To support tracking changes in
static parameter values, the blocks static
revision parameter will be incremented each
time a static parameter value is changed. Also,
the blocks static revision parameter may be
incremented if a static parameter is written but
the value is not changed. If the Actual Mode is
not Out of Service and Reports is selected in
the Feature Select parameter, then this
parameter will be sent to the host system
providing the host has set up alert
communications. Changes to static data while
the block is Out of Service will be reported
when the block transitions to another mode.
UPDATE_STATE 35.2 RO NA
0=Undefined
1=Update reported
2=Update not
reported
0=Undefined
TIME_STAMP 35.3 RO NA 0
STATIC_REVISION 35.4 RO NA 0
RELATIVE_INDEX 35.5 RO NA 0
Block Alarm
BLOCK_ALM
36
UNACKNOWLEDGED 36.1 RW ALL
0=Undefined
1=Acknowledged
2=Unacknowledged
0=Undefined
Data Type: DS-72
This alarm is generated by a nonzero value in
the Block Error. parameter. This alarm has a
fixed priority of 2. For a BLOCK_ALM to be
broadcast to the host the following conditions
must be met:
The feature Reports must be selected
Alert communication with the host must be
setup
In the ALARM_SUM parameter, the disable
bit for Block Alarm must be clear.
ALARM_STATE 36.2 RO NA
0=Undefined
1=Clear reported
2=Clear not reported
3=Active reported
4=Active not reported
0=Undefined
TIME_STAMP 36.3 RO NA 0
SUBCODE 36.4 RO NA 0
VALUE 36.5 RO NA 0
Alarm Summary
ALARM_SUM
37
CURRENT 37.1 RO NA
0: Discrete alarm
7: Block Alarm
All bits: 0
Data Type: DS-74
0=clear, acknowledged, reported, enabled
Current alert status, unacknowledged states,
unreported states, and disabled states of the
alarms associated with the function block. The
Resource block only has two alarms: Write
Alarm and Block Alarm.
UNACKNOWLEDGED 37.2 RO NA
0: Discrete alarm
7: Block Alarm
All bits: 0
UNREPORTED 37.3 RO NA
0: Discrete alarm
7: Block Alarm
All bits: 0
DISABLED 37.4 RW ALL
0: Discrete alarm
7: Block Alarm
All bits: 0
Acknowledge Option
ACK_OPTION
38 RW ALL
0: Discrete Alarm
(Write Lock off)
7: Block Alarm
0: 0
7: 0
Data Type: Bit String
0=Disable
1=Enable
Selection of whether alarms associated with
the block will be automatically acknowledged.
Write Priority
WRITE_PRI
39 RW ALL 0 to 15 0
Data Type: Unsigned8
Priority of the alarm generated by setting
WRITE_LOCK to Unlocked.
−Continued−
5
