Ambient temperature -40 °F (-40.0 °C) to 149 °F (65 °C)
Important
For an open tank installation, consider the ambient temperature
above the tank. Although the meter can operate at 302 °F
(150 °C), with an open tank installation, the maximum ambient
temperature above the tank is limited to 149 °F (65 °C).
Procedure
1. Clamp the long-stem meter to a structure, positioning the clamp to determine the
insertion depth of the meter.
Figure 3-12: Open-tank meter installation (long stem)
2. Confirm the meter tines are away from the tank wall.
Installation Manual Mounting
MMI-20020989 May 2019
Installation Manual 29
