Viscosity • Up to 500 cP (with long tines)
• Up to 20,000 cP (with short tines)
Fluid temperature -40 °F (-40.0 °C) to 302 °F (150 °C)
Ambient temperature -40 °F (-40.0 °C) to 149 °F (65 °C)
Important
For an open tank installation, consider the ambient temperature
above the tank. Although the meter can operate at 302 °F
(150 °C), with an open tank installation, the maximum ambient
temperature above the tank is limited to 149 °F (65 °C).
Procedure
1. Attach the long-stem meter using the fitted flange attachment that's shipped with
the product.
Figure 3-18: Closed-tank installation (fitted flange attachment)
2. To vary the insertion depth of the meter, mount the meter on a standoff section
that attaches to the flange (not provided).
Mounting
Installation Manual
May 2019 MMI-20020989
32 Micro Motion Fork Density Meter
