Figure 3-19: Closed-tank installation (with standoff)
A. Standoff height can vary (provided by customer)
3. Confirm the meter tines are away from the tank wall.
Figure 3-20: Meter placement (away from tank wall)
B
A
A
B
A. 7.87 in (200 mm)
B. 2 in (51 mm)
4. Confirm the meter tines are immersed in fluid.
Installation Manual
Mounting
MMI-20020989 May 2019
Installation Manual 33
