4.2.2 Wire Time Period Signal (TPS) or Discrete Output in
explosion-proof/flameproof or non-hazardous area
CAUTION
Meter installation and wiring should be performed by suitably trained personnel only in
accordance with the applicable code of practice.
Procedure
Wire to the appropriate output terminal and pins (see Figure 4-1).
Installation Manual Wiring
