Quick Panel Operator User Manual Appendix A
GFK-2847AA Jan 2023
Product Certifications and Installation Guidelines 101
Figure 106: Insert Retaining Clamp into Retaining Clamp Plate
WARNING
•
EXPLOSION HAZARD — Do not connect or disconnect equipment power,
communication, audio, or battery unless power has been removed or the area is
known to be non-hazardous.
•
EXPLOSION HAZARD — Substitution of components may impair suitability.
•
EXPLOSION HAZARD — DO NOT VESA MOUNT. Panel mounts only with enclosures
that shall only be opened with the use of a tool in an area where the risk of impact is
low.
•
DO NOT MAKE ANY CONNECTIONS TO THE MINI-USB/MIC TERMINAL AS IT WILL
INVALIDATE THE ATEX APPROVAL. If this equipment is used in a manner not specified
by the manufacturer, equipment protection may be impaired.
