Emerson QuickPanel+ IC755C S06RD Series User Manual

Quick Panel Operator User Manual Section 3
GFK-2847AA Jan 2023
Software 44
3.14.5 Data Types Mapping between PAC Machine Edition
Project and SNMP
When you configure HMI tags in a PAC Machine Edition project and you
would like to use them in SNMP communication, all of the HMI tags are
mapped to the corresponding data type in SNMP as listed in the following
table. To verify this, review the Sequence of HMI Tags object in the MIB
file.
PAC Machine Edition VIEW Data
Types
SNMP Data Types
BOOL
INTEGER
DINT
INTEGER
LREAL
DISPLAYSTRING
STRING
DISPLAYSTRING
Note: The PAC Machine Edition VIEW LREAL data type is mapped to DISPLAYSTRING to retain the data
intact.
You can continue to use the data type override/suffix mechanism in PAC
Machine Edition for the LREAL data type to represent an INT/DINT if you
have configured the data type for driver variables. This enables you to
map to the DISPLAYSTRING data type in the SNMP communication as
well.
For example, for the Emerson SRTP driver, you can override the IO
Address of the LREAL variable LREALVar data type as %R100 [INT]. This
maps the LREALVar to DISPLAYSTRING in the MIB file.
3.14.6 Establish SNMP Communication
NOTICE
SNMP communication requires that both the QuickPanel+ device and the SNMP Manager
running on a machine are connected on a valid Ethernet network.
To establish SNMP communication with the QuickPanel
+
device
1. Download the Project to the network-connected QuickPanel
+
device and start Runtime.
2. Configure the Trap Destinations with the IP Address of the SNMP
Manager.
Note: If you do not want to be notified of Traps, you do not need to configure Trap Destinations.
