Section 4: Pre-installation Checks
This Section provides information and procedures to perform pre-
installation checks of the QuickPanel
+
Operator Interface. Before
installing and using the QuickPanel
+
, complete the following procedures:
•
Section 4.1, Unpacking and Inspection
•
Section 4.2, Basic Set-up
•
Section 4.3, Initial Start-up
•
Section 4.4, Runtime Set-up
•
Section 4.5, Firmware Updates
4.1 Unpacking and Inspection
Upon receipt of the QuickPanel
+
Operator Interface, carefully inspect all
shipping containers for damage. If any part of the system is damaged,
notify the carrier immediately. Save the damaged shipping container for
inspection by the carrier. It is the consignee’s responsibility to register a
claim with the carrier for damage incurred during shipment.
Note: For phone numbers and email addresses, refer to the section Contact Information at the start of
this manual.
After unpacking the unit, record all serial numbers. These are needed to
contact Customer Care during the warranty period. Save all shipping
containers and packing material for future transport or shipping. Verify
that all system components have been received and agree with the order.
If the system received does not agree with your order, contact Customer
Care.
Before initial power-up, inspect the unit for loose or damaged
components. If damage is found (such as bent component leads or loose
components), contact Emerson Automation & Controls for additional
instructions.
CAUTION
Do not apply power to the unit if it has visible damage. Applying power to a unit with
damaged components may cause additional damage.
