Overview..................................................................
Safety Messages....................................................
Calibration Overview..............................................
Calibration Procedures..........................................
This section contains the following transmitter calibration
information:
• Calibration Overview
→ Calibration Considerations
→ Definitions
→ Span Adjustment Range
→ Zero Adjustment Range
• Calibration Procedures
→ Span and Zero Adjustment
Zero Based Calibration Procedure
(LRV is Zero)
Elevated or Suppressed Zero
Calibration Procedure
Coarse Zero Select Jumper Position
Selection Procedure
• Damping Adjustment
• Correction for High Static Line Pressure
→ High Static Pressure Span Effect on Range
Codes 1, 2 and 3 DP Transmitters
→ High Static Pressure Span Correction for
Range Codes 4 and 5 DP Transmitters
→ High Static Line Pressure Zero Correction for
DP Transmitters (All Ranges)
Procedures and instructions in this section may require special
precautions to ensure the safety of the personnel performing
the operation. Refer to the following safety messages before
performing an operation preceded by this symbol:
Explosions can result in death or injury.
• Do not remove the transmitter covers in explosive
environments when the circuit is live.
• Verify that the operating atmosphere of the transmitter
is consistent with the appropriate qualification
Electrical shock can result in death or serious injury.
• Avoid contact with the leads and terminals when the
