Reference Manual
00809-0100-4835 Rev BE
February 2018
Rosemount 3150 Series
Transmitter Spare Parts
74
Spare Parts Category
(1)
Rosemount
Order Number
Quantity Required
(2)
Item Number
(3)
Part Description
Process Flange Kits for DP Transmitters
(5)
-
Flange Assembly w/Qty (2) C-rings: Flange Code F0
9,10
1
03154-5022-1001
Flange Assembly w/Qty (2) C-rings: Flange Code F1
9,10
1
03154-5022-2200
Flange Assembly w/Qty (2) C-rings: Flange Code F2
9,10
1
03154-5022-0011
Flange Assembly w/Qty (2) C-rings: Flange Code F3
9,10
1
03154-5022-2211
Flange Assembly w/Qty (2) C-rings: Flange Code F4
9,10
1
03154-5022-1111
Flange Assembly w/Qty (2) C-rings: Flange Code F5
9,10
1
03154-5022-0022
Flange Assembly w/Qty (2) C-rings: Flange Code F6
9,10
1
03154-5022-0033
Flange Assembly w/Qty (2) C-rings: Flange Code F7
9,10
1
03154-5022-2233
Flange Assembly w/Qty (2) C-rings: Flange Code F8
9,10
1
03154-5022-3333
Process Flange Kits for GP Transmitters
(5)
-
Flange Assembly w/Qty (2) C-rings: Flange Code F0
9,10
1
03154-5032-1001
Flange Assembly w/Qty (2) C-rings: Flange Code F1
9,10
1
03154-5032-0200
Flange Assembly w/Qty (2) C-rings: Flange Code F2
9,10
1
03154-5032-0001
Flange Assembly w/Qty (2) C-rings: Flange Code F3
9,10
1
03154-5032-0201
Flange Assembly w/Qty (2) C-rings: Flange Code F4
9,10
1
03154-5032-0101
Flange Assembly w/Qty (2) C-rings: Flange Code F5
9,10
1
03154-5032-0002
Flange Assembly w/Qty (2) C-rings: Flange Code F6
9,10
1
03154-5032-0003
Flange Assembly w/Qty (2) C-rings: Flange Code F7
9,10
1
03154-5032-0203
Flange Assembly w/Qty (2) C-rings: Flange Code F8
9,10
1
03154-5032-0303
Process Flange Kits for AP Transmitters
(5)
-
Flange Assembly w/Qty (1) C-ring: Flange Code F0
9,10
1
03154-5042-2001
Flange Assembly w/Qty (1) C-ring: Flange Code F1
9,10
1
03154-5042-0200
Flange Assembly w/Qty (1) C-ring: Flange Code F2
9,10
1
03154-5042-0001
Flange Assembly w/Qty (1) C-ring: Flange Code F3
9,10
1
03154-5042-0201
Flange Assembly w/Qty (1) C-ring: Flange Code F4
9,10
1
03154-5042-0101
Flange Assembly w/Qty (1) C-ring: Flange Code F5
9,10
1
03154-5042-0002
Flange Assembly w/Qty (1) C-ring: Flange Code F6
9,10
1
03154-5042-0003
Flange Assembly w/Qty (1) C-ring: Flange Code F7
9,10
1
03154-5042-0203
Flange Assembly w/Qty (1) C-ring: Flange Code F8
9,10
1
03154-5042-0303
Mounting Bracket Kits
-
Panel Mounting Bracket Kit, Carbon Steel, Transmitter to
Bracket SST Mounting Hardware Included, 3152/3153
1 03153-5112-0004
Panel Mounting Bracket Kit, SST, Transmitter to Bracket SST
Mounting Hardware Included, ALL MODELS
1 03154-5112-0003
2-inch Pipe Mounting Bracket Kit (2 U-bolts), SST, Transmitter
to Bracket SST Mounting Hardware Included, ALL MODELS
1 03154-5113-0004
3150 Transmitter to Bracket Mounting Hardware (Bolts &
Washers), SST
1 03154-5115-0002
Miscellaneous Items
-
3150 Series Cover Wrench
1
A
03154-5025-0001
(1) Rosemount recommends one spare or kit for every 25 transmitters in Category “A”, one spare part or kit for every 50
transmitters in Category “B”, and one spare part or kit for every 5 transmitters in Category “C”.
(2) The quantity stated is sufficient to service one transmitter.
(3) The item number corresponds with Figure 5-1 in Section 5: Maintenance & Troubleshooting of this reference manual.
(4) Terminal Block with Transient Protection is not qualified for use with Rosemount 3153N or 3154N models.
(5) See Transmitter Product Data Sheet for information regarding process flange configuration.
