Emerson Rosemount MultiVariable 3051S Series User Manual

4. The Engineering Assistant Device Connection screen will appear, see
Figure 6-8.
Figure 6-8: Engineering Assistant Device Connection Screen
5. Select the Search button located in the lower right hand corner of the
screen. Engineering Assistant will begin to search for connected
devices.
6. When the search is completed, select the device to communicate with
and select Send Configuration button.
Note
After the configuration is sent to the device, saving the configuration
file is recommended. The user can select the Save button on the Save/
Send screen or select Save from the program menu.
Once the configuration is finished being sent to the device, the user
will be notified by a pop-up dialog box.
7. If finished with the configuration process, close Engineering Assistant.
October 2018 Quick Start Guide
Quick Start Guide 25

Emerson Rosemount MultiVariable 3051S Series Specifications

General

Type	MultiVariable Transmitter
Accuracy	±0.04% of span
Ambient Temperature Limit	-40 to 185 °F (-40 to 85 °C)
Approvals	FM, CSA, ATEX, IECEx
Service	Liquid, Gas, Steam
Warranty	5 years
Process Temperature Range	-40 to 257°F (-40 to 125°C)
Response Time	100 ms
Power Supply	10.5 to 42 V DC
Communication Protocols	HART, FOUNDATION Fieldbus, PROFIBUS
Housing Material	Aluminum
Display	Optional LCD
Process Connection	1/4" NPT
Electrical Connection	1/2–14 NPT, M20 x 1.5
Enclosure Rating	NEMA 4X, IP66
Measurement Types	Differential Pressure, Static Pressure, Temperature
