9.1 Documentation
As well as the Commander SK Getting Started Guide, a number of other guides are
available for Commander SK:
Commander SK Technical Data Guide
This gives all the technical data for the drive, such as:
Commander SK Advanced User Guide
This gives detailed information on all of the drive’s advanced parameters and also on
the serial communications. Furthermore, it gives set-up examples for the drive.
Option Module User Guides / Installation Sheets
These guides provide detailed information and set-up instructions for the various
options available for Commander SK.
All of these guides can be found on the CD supplied with the drive or downloaded from
www.controltechniques.com.
CT USB comms cable
Cable with isolation RS232 to RS485 converter. For connecting
PC/Laptop to the drive when using CTSoft or SyPTLite
AC input line reactors To reduce supply harmonics
CTSoft
Software for PC or Laptop which allows the user to commission
and store parameter settings
SyPTLite
Software for PC or Laptop which allows the user to program PLC
functions within the drive
NEMA 1 +
UL type 1 kit
Bottom metal gland plate, top cover and side covers to allow the
drive to comply with the requirements of UL type 1
Option name Function Picture
• Fuse sizes • Pollution degree • Weights
• Cable sizes • Vibration specifications • Losses
• Braking resistor information • Humidity • De-rating info
• IP ratings • Altitude • EMC filter info
