See Commander SK Advanced User Guide for advanced parameter details.
6.3 Parameter descriptions - Level 3
Set Pr 71 to Pr 80 to the required advanced parameter number to be accessed.
The value within these parameters will be displayed in Pr 61 to Pr 70. Pr 61 to Pr 70 can
then be adjusted to change the value within a parameter.
See Commander SK Advanced User Guide for further details.
6.4 Diagnostic parameters
The following read only (RO) parameters can be used as an aid to fault diagnosis on the
drive. See Figure 8-1 Diagnostics logic diagram on page 49.
Some parameters are only implemented if the drive is disabled, stopped or tripped and
the STOP/RESET key is pressed for 1s.
NOTE
No Function Range Defaults Type
71
to
Pr 61 to Pr 70 set up
0 to Pr 21.51
RW
80
No Function Range Type
81
Frequency reference selected ±Pr 02 Hz RO
82
Pre-ramp reference ±Pr 02 Hz RO
83
Post-ramp reference ±Pr 02 Hz RO
84
DC bus voltage 0 to Drive maximum Vdc RO
85
Motor frequency ±Pr 02 Hz RO
86
Motor voltage 0 to Drive rating V RO
87
Motor speed ±9999 rpm RO
88
Motor current +Drive maximum A RO
89
Motor active current ±Drive maximum A RO
90
Digital I/O read word 0 to 95 RO
91
Reference enabled indicator OFF or On RO
92
Reverse selected indicator OFF or On RO
93
Jog selected indicator OFF or On RO
94
Analog input 1 level 0 to 100 % RO
95
Analog input 2 level 0 to 100 % RO
