ER5000 —
194
The ERTune™ Program: Power User
Deadband
This is the Pulse Width Deadband, the “deadband within a
deadband” of the Integral Deadband. When feedback falls within
this inner range, Pulse Mode stops responding.
Pulse Width Deadband is set to a much smaller level than Integral
Deadband, allowing the ER5000 to respond to a very small level
or error.
• Integral Deadband is generally set within a range of 0–0.5%
of feedback.
• Pulse Width Deadband is set by counts of error. Each count
equates to .03% of feedback. Pulse deadband is generally set
at 1–3 counts, which equates to .03–.09% of feedback.
To change the Pulse Width settings
1. Enter a new value in the Period, Width or Deadband eld and
press the Tab key.
NOTENOTE
CAUTIONCAUTION
WARNINGWARNING
The values should be changed incrementally until the
desired response is achieved.
