14 15
Network Installation
Conguring the Online Connection Kit
➤ Ensure the Online Connection Kit is receiving a Private or Static IP address via
DHCP Server. A public IP will not work;
➤ Ensure that the MAC address is properly Whitelisted if it needs to bypass
a login (splash) page to be able to reach the internet. The MAC address is
printed on a white sticker on the bottom of the Online Connection Kit.
➤ The Online Connection Kit’s open ports are 22, 80, and 443.
HVAC Controller Installation
High voltage HVAC Controller installation
The high voltage HVAC Controller can control HVAC units that would typically use
line voltage controls.
The HVAC Controller outputs are the same voltage as the incoming power source.
Insert the threaded hub through a knock-out hole of your enclosure. Use a standard
locknut to secure the HVAC Controller to the enclosure.
The connections between the HVAC unit and the HVAC Controller will be terminated
inside the enclosure. Please ensure the installation respects the prevalent local
electrical code.
The occupancy output of the HVAC Controller (i.e. a relay output that energizes
when the room is occupied) will also produce the same voltage as the incoming
power source. If this signal needs to be used with other systems, please install a relay
whose coil voltage requirements matches the incoming power source of the HVAC
Controller.
Take note of the serial number on the HVAC Controller before closing the enclosure.
This number is necessary to pair the HVAC Controller with the Verdant thermostat in
the same room.
THE HVAC CONTROLLER ANTENNA MUST BE FACING THE THERMOSTAT AND
MUST NOT BE TOUCHING OR ENCLOSED BY ANY METAL COMPONENTS IN THE
HVAC UNIT.
THE HVAC CONTROLLER MUST BE MOUNTED OUTSIDE OF ANY EXISTING METAL
ENCLOSURE BY USING THE THREADED HUB BUILT INTO THE HVAC CONTROLLER.
