16 17
HVAC Controller Installation
High voltage HVAC Controller installation (cont’d)
The thermostat can control units using line voltage valves (heating and cooling) and
2 fan speeds.
➤ Connect cooling valve to terminal 2 and terminal 5 (black and yellow wires);
➤ Connect heating valve to terminal 2 and terminal 4 (black and white wires);
➤ Connect High Fan speed to terminal 2 and terminal 9 (black and green wires);
➤ Connect Low Fan speed to terminal 2 and terminal 8 (black and purple wires);
Thermostat Installation
THE THERMOSTAT’S OCCUPANCY SENSOR SHOULD FACE THE BED AREA OF
THE ROOM OR THE AREA WHERE THE OCCUPANT WILL SPEND THE MOST
TIME.
THE THERMOSTAT MUST NOT BE INSTALLED IN THE VICINITY OF METAL
STRUCTURES OR SURFACES INCLUDING METAL AIR DUCTING THAT MAY BE
IN THE WALL.
METAL STRUCTURES AND SURFACES SIGNIFICANTLY REDUCE THE RANGE
OF THE WIRELESS SIGNAL.
DO NOT OVER TIGHTEN THE BACK PLATE TO THE WALL. FOR UNEVEN
SURFACES, CONSIDER INSTALLING A WALL PLATE.
Mounting the Thermostat to the Wall
➤ Select the appropriate installation location for the thermostat, taking into
account the following;
➤ With the faceplate removed, place the thermostat on the wall in the
installation location and mark location for drilling holes for the two (2)
mounting screws;
➤ Drill two (2) 3/16” holes in the wall and insert the two (2) supplied wall
anchors;
➤ Use the two (2) supplied screws to securely mount the thermostat to the wall;
➤ Insert two (2) AA-cell batteries (not supplied) into the thermostat battery
compartment.
Terminal
Terminal
Connection
Wire Color
1 Line Voltage Red
2 Neutral Black
3
4 Heating White
5 Cooling Yellow
6 Aux (Occupancy Out) Brown
7
8 Fan Low Purple
9 Fan High Green
To Next Page
