2 Product information
This guide covers the Unidrive M600 product.
Table 2-1 Supported operating modes
* Possible via an option module.
2.1 Model number
The way in which the model numbers for the Unidrive M product range is formed is illustrated below:
Figure 2-1 Model number
* Only shown on frame size 9E and 10 identification label.
For simplicity a Frame 9 drive with no internal choke (i.e. Model 09xxxxxxE) is referred to as a Frame
9E and a Frame 9 drive with an internal choke (i.e. Model 09xxxxxxA) is referred to as a Frame 9A.
Any reference to Frame 9 is applicable to both sizes 9E and 9A.
Product
Supported operating modes
Open-
Loop
RFC-A
RFC-A
Sensorless
RFC-S
RFC-S
Sensorless
Regen
Unidrive M600 3 * 3
33
Identification Label
Electrical Specifications
Derivative
Unidrive M600
Product Line
Frame Size:
Voltage Rating :
Current Rating:
Heavy Duty current rating x 10
Power Format:
Reserved
0
Optional Build
Customer Code
01
A
B
1
0
0
Customer Code:
00 = 50 Hz
01 = 60 Hz
Reserved:
Conformal Coating:
0 = Standard
IP / NEMA Rating:
1=IP21/NEMA1
Brake T
ransistor
:
B=Brake
Cooling
:
A=Air
Documentation
1
Documentation:
0 - Supplied separately
1 - English
2 - 200 V (200 - 240
- 400 V (380 - 480
- 575 V (500 - 575
- 690 V (500 - 690
± 10 %)
4
±
±
±
10 %)
510 %)
610 %)
Power
Format
M600 - 03 4 00078 A
Configuration*
1
A - AC in AC out (with internal choke)
D - DC in AC out (Inverter)
C - AC in DC out (Rectifier)
E - AC in AC out (without internal choke)
Configuration:
1 - Standard
U - No Control
M - Master
F - Follower
NOTE
Unidrive M600 Getting Started Guide English Iss1.book Page 7 Friday, April 25, 2014 2:08 PM
