Table 2-8 Option modules, Keypad and additional options available
For more information refer to the Drive User Guide and the relevant option module user guide.
Type Name Further details
Feedback
15-way D-type
converter
Drive encoder input converter
Provides screw terminal interface for encoder wiring and spade
terminal for shield.
Single ended
encoder interface
(15 V or 24 V)
Single ended encoder interface
Provides an interface for single ended ABZ encoder signals,
such as those from hall effect sensors. 15 V and 24 V versions
are available.
Fieldbus
KI-485 Adaptor
485 Comms Adaptor
485 Comms adaptor provides 485 communication interface. This
adaptor supports 115 k Baud, node addresses between 1 to 16
and 8 1 NP M serial mode.
SI-PROFIBUS
Profibus option
PROFIBUS adapter for communications with the drive.
SI-DeviceNet
DeviceNet option
DeviceNet adapter for communications with the drive.
SI-CANopen
CANopen option
CANopen adapter for communications with the drive.
Automation
(I/O
expansion)
SI-I/O
Extended I/O
Increases the I/O capability by adding the following
combinations: Digital I/O, Digital Inputs, Analog Inputs
(differential or single ended), Analog Output, Relays.
Automation
(Applications)
MCi200
Machine Control Studio Compatible Applications Processor
2nd processor for running pre-defined and/or customer created
application software.
MCi210
Machine Control Studio Compatible Applications Processor
(with Ethernet communications)
2nd processor for running pre-defined and/or customer created
application software with Ethernet communications.
SI-Applications
Plus
SyPTPro Compatible Applications Processor (with CTNet)
2nd processor for running pre-defined and/or customer created
application software with CTNet support. (Can be used in slot 3
only).
SI-Register
SyPTPro Compatible Applications Processor
2nd processor for running position capture functionality with
CTNet support. (Can be used in slot 3 only).
Keypad
KI-Keypad
LCD keypad option
Keypad with a LCD display.
KI-Keypad RTC
LCD keypad option
Keypad with a LCD display and real time clock.
Back-up
SD Card Adaptor
SD Card Adaptor
Allows the drive to use an SD card for drive back-up.
SMARTCARD
SMARTCARD
Used for parameter back-up with the drive.
