5.5 Advanced menus
The advanced menus consist of groups or parameters appropriate to a specific function or feature of
the drive. Menus 0 to 41 can be viewed on the KI-Keypad. The option module menus are displayed
as S.mm.ppp. Where S signifies the option module slot number and the mm.ppp signifies the menu
and parameter number of the option module’s internal menus and parameter. Menu 4.00.xxx is the
same as menu 24.xxx.
Table 5-2 Advanced menu descriptions
*Only displayed when the option modules are installed.
Menu Description
0 Commonly used basic set-up parameters for quick / easy programming
1 Frequency / Speed reference
2Ramps
3 Frequency slaving, speed feedback and speed control
4 Torque and current control
5 Motor control
6 Sequencer and clock
7 Temperature monitoring
8 Digital I/O
9 Programmable logic, motorized pot, binary sum, timers and scope
10 Status and trips
11 Drive set-up and identification, serial communications
12 Threshold detectors and variable selectors
13 Standard motion control
14 User PID controller
15 Option module slot 1 set-up menu
16 Option module slot 2 set-up menu
17 Option module slot 3 set-up menu
18 General option module application menu 1
19 General option module application menu 2
20 General option module application menu 3
21 Second motor parameters
22 Menu 0 set-up
23 Not allocated
24 Ethernet module (slot 4) set-up menu
25 Option module slot 1 application parameters
26 Option module slot 2 application parameters
27 Option module slot 3 application parameters
28 Option module slot 4 application parameters
29 Reserved menu
30 Onboard user programming application menu
31-41 Advanced motion controller setup parameters
Slot 1 Slot 1 option menus*
Slot 2 Slot 2 option menus*
Slot 3 Slot 3 option menus*
Slot 4 Ethernet menus
Unidrive M702 Getting Started Guide English iss3.book Page 43 Friday, August 29, 2014 2:33 PM
