3.6 Terminal size and torque settings
Table 3-1 Drive control and relay terminal data
Table 3-2 Drive power terminal data
Model Connection type Torque setting
All Plug-in terminal block 0.5 N m (0.4 lb ft)
Model size
AC terminals DC and braking Ground terminal
Recommended
3 and 4
Plug-in terminal block T20 Torx (M4)
T20 Torx (M4) /
M4 Nut (7 mm AF)
0.7 N m (0.5 lb ft) 2.0 N m (1.47 Ib ft) 2.0 N m (1.47 Ib ft)
5
Plug-in terminal block
1.8 N m (1.3 lb ft)
T20 Torx (M4) /
M4 Nut (7 mm AF)
M5 Nut (8 mm AF)
1.5 N m (1.1 lb ft) 1.5 N m (1.1 lb ft) 2.0 N m (1.47 Ib ft)
6
M6 Nut (10 mm AF)
6.0 N m (4.42 Ib ft)
7
M8 Nut (13 mm AF)
12.0 N m (8.85 Ib ft)
8 to 10
M10 Nut (17 mm AF)
15.0 N m (11.1 Ib ft)
