Emerson Unidrive M702 Getting Started Guide

Unidrive M702 Getting Started Guide 21
Issue Number: 4
Safety information Product information
Mechanical
installation
Electrical
installation
Getting started
Basic parameters
(Menu 0)
Running the motor
NV Media Card
Operation
Further information
UL listing
information
Figure 3-3 Surface mounting dimensions (size 8 to 10)
257 mm (10.12 in)
Æ9mm(0.35in)
(4 holes)
784 mm (30.87 in)
10 mm
(0.39 in)
26 mm
(1.02 in)
259 mm (10.20 in)
(0.35 in)
x 4 holes
1051 mm (41.38 in)
9mm
(0.35 in)
26 mm
(1.02 in)
9E
Æ
9.0 mm
8
10
Unidrive M702 Getting Started Guide English iss3.book Page 21 Friday, August 29, 2014 2:33 PM
