3.5 Surface mounting
Figure 3-2 Surface mounting dimensions (size 3 to 7)
6.0 mm
(0.24 in)
73.0 mm (2.87 in)
Æ 5.5 mm
(0.22 in)
370 mm
(14.57 in)
3
106 mm (4.17 in)
375 mm
(14.76 in)
8mm
(0.32 in)
53 mm
(2.09 in)
53 mm
(2.09 in)
4
106 mm (4.17 in)
9mm
(0.35 in)
8mm
(0.32 in)
375 mm (14.76 in)
Æ 6.5 mm
(0.26 in)
5
Æ 6.5 mm
(0.26 in) x 4 holes
9mm
(0.35 in)
378 mm
(14.88 in)
196 mm
(7.72 in)
6.0 mm
(0.24 in)
Æ
7.0 mm
(0.27 in)
7.0 mm
(0.28 in)
6
220 mm (8.66 in)
Æ
9mm (0.35 in)
538 mm (21.18)
25 mm
(0.98 in)
10 mm
(0.39 in)
7
Unidrive M702 Getting Started Guide English iss3.book Page 20 Friday, August 29, 2014 2:33 PM
