Emerson Unidrive M702 Getting Started Guide

Unidrive M702 Getting Started Guide 31
Issue Number: 4
Safety information Product information
Mechanical
installation
Electrical
installation
Getting started
Basic parameters
(Menu 0)
Running the motor
NV Media Card
Operation
Further information
UL listing
information
Figure 4-3 Size 5 power and ground connections
The upper terminal block (1) is used for AC supply connection.
The lower terminal block (2) is used for Motor connection.
Optional
braking
resistor
Thermal
overload
protection
device
BR
+DC
-DC
DC / Brake connections
BR
Optional
braking
resistor
Thermal
overload
protection
device
DC -
DC +
L1 L2
L2L1 L3 U V W
Optional EMC
filter
Optional
line reactor
Fuses
L3
Mains
Supply
Motor
Optional ground
connection
Supply
Ground
PE
AC Connections Motor Connections
1
2
Unidrive M702 Getting Started Guide English iss3.book Page 31 Friday, August 29, 2014 2:33 PM
