MicroVission Retrot Instructions • 35391MVRF
Table 2. MicroVission Kits (1 of 3)
Kit VPN Items contained Description Quantity
KT1133A
SUPPORT BRACKETS
1800C NUT 3/8-16NC HEX STN STL 2
93LSS WASHER 3/8 LOCK STN STL 304 4
93SS1 WASHER 3/8 FLAT STN STL 304 2
2796CJSS SCREW 3/8-16NCX1-1/4 CAP HEX 17-4 SS 2
41813Z SUPPORT 1/4X3X28 MICROVISSION W/HOLES 2
KT1133A1
PANEL MOUNTING
(Retrot)
93SS1 WASHER 3/8 FLAT STN STL 304 8
93LSS WASHER 3/8 LOCK STN STL 304 8
1800C NUT 3/8-16NC HEX STN STL 8
9994ASJ ISOLATOR 3/8-16 VIBRATION SS STUDS 4
KT1133A3
DECALS
(Retrot)
40680BJ24V DECAL WARNING NO WIRE RH SIDE PNL 24V 1
40680BK DECAL WARNING READ OPERATORS MANUAL 1
40680BM DECAL DANGER POSSIBLE ELECTROCUTION 1
40680BR DECAL WARNING NO WIRE ON TOP PANEL 1
1811DESIPAK DESICCANT TYVEK PACKET 1
3669SD CARD SECURE DIGITAL, XGb 1
KT1133A4
ELECTRICAL
3122Q2 CORD GRIP RSR1005 1/2 HUB 1/4 DIA 4
3122A CORD GRIP RSR-20732-4 REMKE 2
2891B CONNECTOR .187-.312 CORD 1/2 HUB 1
1652B HUB 3/4 SCRU-TITE 5
2748B BUSHING 3/4X1/2 REDUCING 5
1242B LOCKNUT 3/4 CONDUIT 2
2762B RING 3/4 SEALING 2
2763B BLANK 3/4 KNOCK-OUT SNAP-IN S75 2
KT1133A5
ELECTRICAL
FITTINGS/
ACCESSORIES
3122Q2 CORD GRIP RSR1005 1/2 HUB 1/4 DIA 4
3122G CORD GRIP RSR-2304-5 REMKE 2
2891B CONNECTOR .187-.312 CORD 1/2 HUB 1
1652B HUB 3/4 SCRU-TITE 5
2748B BUSHING 3/4X1/2 REDUCING 5
1242B LOCKNUT 3/4 CONDUIT 2
2762B RING 3/4 SEALING 2
2763B BLANK 3/4 KNOCK-OUT SNAP-IN S75 2
