MicroVission Retrot Instructions • 35391MVRF
Kit VPN Items contained Description Quantity
KT1133A10
BLOCK AND BLEED
(Retrot)
27100D BRACKET 4HOLE BLOCK/BLEED VERTICAL 1
2098A CONN 1/4ODTX1/4FPT BULKHEAD FEM 4
3031T VALVE 1/4MPTXFPTXFPT TRANSDUCER 4
13264B PLUG 1/4 HEX HD B16.11 SA105 4
1101A BUSHING 1/4X1/8 HEXAGON #600 4
3365G PLUG 1/8 PLASTIC THREADED 4
41173T4 NAMEPLATE 3/4X2 SUCTION PRESSURE 1
41173B4 NAMEPLATE 3/4X2 OIL PRESSURE 1
41173X6 NAMEPLATE 3/4X2 DISCHARGE PRESS #1 1
41173Y6 NAMEPLATE 3/4X2 DISCHARGE PRESS #2 1
1726E NUT 1/2-13NC-2B HEX HVY PLAIN 2
2796EL SCREW 1/2-13NCX1-3/4 CAP HEX HD GR5 2
13265G WASHER 1/2 FLAT BLACK 4
13165F WASHER 1/2 LOCK CARB STL 2
KT1133A11
MOUNTING
SUPPORT
A41813M SUPPORT 2-16CYL CONTROLLER MICROVISSION 1
13265K WASHER 3/4 FLAT BLACK 8
1726H NUT 3/4-10NC-2B HEX HVY PLAIN 4
2796HQ SCREW 3/4-10NCX2-3/4 CAP HEX HD GR5 4
KT1133A12
PROCESS TEMP RTD,
WELL & CABLE
2611G DETECTOR -58/392F TEMP RESIST W/TURCK 1
3122L7 CABLE 4M BLACK PLTC ACTUATOR POSITION 1
2611J WELL 1/4X1/2 RTD LAGGING 1018CS 1
KT24x20MV
KIT 24X20
A42159A PANEL 20X24 MICROVISSION 2-8CYL 1.00
KT1133A11 KIT MOUNTING SUPPORT 1.00
KT1133A1 KIT PANEL MOUNTING MICROVISSION RETRO 1.00
KT1133A8 KIT INSTRUMENTATION MICROVISSION RETRO 1.00
KT1133A5 KIT ELECTRICAL FITTINGS/ACCESSORIES 1.00
2611F WELL 1/4X1/2 RTD 1018CS 4.00
2611N DETECTOR -58/122DEG TEMP RESIST 4-20MA 1.00
2611F WELL 1/4X1/2 RTD 1018CS 1.00
3122L7 CABLE 4M BLACK PLTC ACTUATOR POSITION 1.00
KT1133A10 KIT BLOCK AND BLEED MICROVISSION RETRO 1.00
A42159A PANEL 20X24 MICROVISSION 2-8CYL 1.00
3669CT TRANSMITTER MOTOR CURRENT 1.00
KT822A
MOUNTING
HARDWARE
1726D NUT 7/16-14NC-2B HEX HVY PLAIN 2.00
13265FZ WASHER 7/16 USS ZINC PLTD 4.00
13165ES WASHER 7/16 LOCK 304SS 2.00
41801G BRACKET, CONTROL PANEL RETROFIT 1.00
Table 2. MicroVission Kits (3 of 3)
