1592028010 XWEB300D_500D_500 EVO STP GB r1.2 12.06.2017.doc XWEB3000/5000 EVO 13/22
LED
Led
Colour
Description
Pwr
Green
On when the system is powered
HDD
Blue
On when the disc executes physical writing operations
Rec
Blue
On when the system is recording data
Ser1/Ser2
Blue
On when the system is reading and/or writing on serial port 485
Mdm
Blue
On when the system runs operations with the analogue modem
DI1/DI2
Blue
On when the system detects the digital input as being active
Aux1/Aux2/Aux3
Blue
On when the system sets the relay output as active
Alarm
Red
On when the system detects an alarm
If you intend to use external peripheral devices, always connect them to the unit before turning it on. Caution:
always and only connect the external peripheral devices before turning on XWEB-EVO. If necessary, consult
the instructions manual for the individual connected device.
When the system has been launched, the home page will appear (also known as the login page). Enter user
name and password to login.
Note that the user interface for the connection is always the same, regardless of what type of access has
been set up: local PC, Intranet or Internet.
