ZB38
~
ZB48 (BOM 524)
ZB Series
Dimensions Brazing Connection
Compressor model
ZB38/45KQ(E)
ZB48KQ(E)
A±3
437.7
443.4
B±3
409.6
413.7
D
124.7
128.7
ø185.5
233.2 ±3.0
296.7 ±3.0
A
B
See Detail A
E:
12.78-12.90 I.D.
10.1 Min
Copper Plated Steel
Discharge Fitting/
Check Valve
22.30-22.43 I.D.
19.9 Min
0.06 Min Thick
Interior Copper Plated
Steel Suction Fitting
ø17.45 Pin Circle
Models: TFD, TFE,TFM, TF7
ø13.46 Pin Circle
Models: PFJ, PFV, TFW, TF5, PFZ
Scale 3:2
A B
233.2
296.7
19.1
12.7
Detail A
Scale 2:1
245.6
122.8
190.5
95.3
95.3
103.5
122.8
190.5
245.6
250.4
D
242.3
62.2
44° 31°
F:
19.10-19.25 I.D.
16.9 Min
Copper Discharge Fitting/
Steel Check Valve
