Emerson ZB Copeland Scroll User Manual

49
ZB66
~
ZB88 (BOM 524)
ZB Series
Dimensions Brazing Connection
242.5 MAX
242.5 MAX
121.3
190.5
190.5
95.3
95.3
133.0
121.3
76.8
142.3
30°
40°
157.8
164.0
4x ø19.00-19.50
121.2
47.9
47.5
95.0
ø17.45
Pin Circle
T-Box layout
Standard
Section A-A
Scale 1:1
242.8
232.2
533.2
501.2
122.1
See Detail FOOT
ø22.30
~
22.42 ID
20.0 Min.
0.038 Min. Thick
Exterior and Interior Copper
Discharge Fitting/
Steel Check Valve
ø34.84
~
35.02 ID
22.6 Min
0.038 Min. Thick
Exterior and Interior Copper Plated
Steel Suction Fitting
122.1 242.8
501.2
533.2
19.1
12.6
Detail FOOT
Scale 1:1
