Emerson ZB Copeland Scroll User Manual

3
ZB Series
Nomenclature & BOM
ZB 76 K Q E - T F D - XXX
Generation
Compressor
Family
High/Medium Temp
Refrigeration
Capacity @ 60Hz
(Medium Temperature
Condition: Btu/h)
Base Capacity
K x 1000
M x 10000
Bill of Material
Lubricant
Blank: Mineral Oil
E: Ester Oil
Compressor Motor
Code Description
P: Single-phase
T: Three-phase
Motor voltages
V Ph Hz
J 220-240 1 50
265 1 60
V 200 1 50
208-230 1 60
D 380-420 3 50
460 3 60
5 200-220 3 50
200-230 3 60
7 380 3 60
Bill of Material (BOM)
Compressor
Model
BOM
Number
523
524
558
559
523*
524*
550
551
Suction & Discharge
Brazing Connection
X
X
X
X
Suction & Discharge
Rotalock Connection
X
X
X
X
Oil Sight
Glass
X
X
X
X
Schrader
Valve
X
X
ZB15-ZB48
ZB58-ZB114
*Not applicable for ZB95/114 models.
Compressor Motor Protection
Code Description
F: Inherent internal line break motor
protector
W: Electronic motor protection with
themistors and control module in
the terminal box

Emerson ZB Copeland Scroll Specifications

General

Brand	Emerson
Model	ZB Copeland Scroll
Category	Compressor
Language	English
