Emerson ZB Copeland Scroll User Manual

58
ZB95
~
ZB114 TFD (BOM 550)
ZB Series
Dimensions Brazing, Sight Glass & Oil Schrader Valve
242.5 MAX
242.5 MAX
121.3
95.0
ø17.45
Pin Circle
47.5
47.9
121.2
121.3
190.5
190.5
95.3
160.0
95.3
76.6
142.3
157.8
164.0
132.8
30°
30°
40°
T-Box Layout
Standard
Section
A-A
Scale 1:1
Sightglass Layout
T-Box Removed
551.6
519.6
140.5
261.2
92.6
See Detail FOOT
See Detail VALVE
234.0
ø34.84-35.02 ID
22.6 Min
0.06 Min Thick Exterior
And 0.038 Min Thick
Interior Copper Plated Steel
Suction Fitting
ø22.30-22.42 ID
20.0 Min Copper
Discharge Fitting/Steel
Check Valve
140.5
92.6
261.2 519.6 551.6
33.3
12.7
Spacer-Mounting Assm
Per Bill of Material
Detail FOOT
Scale 1:1
Detail
VALVE
Scale 3:4
85.5
