Emerson ZB Copeland Scroll User Manual

4
ZB15
~
ZB88
ZB Series
Application Envelope
ZB95/ZB114 (TFD Motor Only)
60
70
50
40
30
20
10
-15 -10 -5 0 5 10 15
Evaporating Temp.
o
C
Condensing Temp.
o
C
60
70
50
40
30
20
10
-15 -10 -5 0 5 10 15
Evaporating Temp.
o
C
Condensing Temp.
o
C
ZB95/ZB114 (TW7, TW5 Motors)
60
70
50
40
30
20
10
-15 -10 -5 0 5 10 15
Evaporating Temp.
o
C
Condensing Temp.
o
C
R22
Note:
1. Envelope In Non Shaded Region, max return gas temperature of 18.3°C
2. Envelope In Shaded Region, Max superheat of 11K only
3. TW5-R22 approved only at 60Hz.
Note:
1. Envelope In Non Shaded Region, max return gas temperature of 18.3°C
2. Envelope In Shaded Region, Max superheat of 11K only
Note:
1. Envelope In Non Shaded Region, max return gas temperature of 18.3°C
2. Envelope In Shaded Region, Max superheat of 11K only
