Emerson ZB Copeland Scroll User Manual

59
ZB95
~
ZB114 TW7/TW5 (BOM 550)
ZB Series
Dimensions Brazing, Sight Glass & Oil Schrader Valve
551.5
519.5
140.5
182.0
See Detail FOOT
See Detail VALVE
ø22.30
~
22.42 ID
20.0 Min.
0.038 Min. Thick Exterior
and Interior Copper Plated
Discharge Fitting/
Steel Check Valve
ø34.84
~
35.02 ID
22.6 Min
0.038 Min. Thick Exterior
and Interior Copper Plated
Steel Suction Fitting
242.5 MAX
242.5 MAX
121.3
121.3
190.5
190.5
95.3
95.3
76.8 207.4
164.0
173.8
133.0
30°
40°
Terminal Box layout Standard
Scale 3:4
33.3
12.6
Detail FOOT
Scale 1:1
85.5
92.6
Detail VALVE
Scale 3:4
