Emerson ZB Copeland Scroll User Manual

50
ZB15
~
ZB29 (BOM 523)
ZB Series
Dimensions Rotalock Connection
ø17.45 Pin Circle
Models: TFD, TFE, TFM, TF7
ø13.46 Pin Circle
Models: PFJ, PFV, TFW, TF5, PFZ
Scale 2:1
19.1
13.1
A
B
C D
Detail B
Scale 2:1
19.1
13.1
A
B
C D
Detail B
Scale 2:1
Compressor model
ZB15/19KQ(E)
ZB21KQ(E)
ZB26KQ(E)
ZB29KQ(E)
A±3
363.8
386.4
400.8
417.8
B
338.3
360.9
372.9
389.9
C
244.5
264.4
277.1
294.1
D±3
202.9
222.8
235.5
252.5
1
1
12
1
A
B
C D
Ø165.9
See Detail B
25.4 Thread
Rotalock Spud
Discharge Fitting
31.75 Thread
Rotalock Spud
Suction Fitting
237.9-243.9
121.5
190.5
95.3
95.3
107.2
64.4
239.0
227.8
190.5
116.7
49°
31.0°
