Emerson ZB Copeland Scroll User Manual

51
ZB38
~
ZB48 (BOM 523)
ZB Series
Dimensions Rotalock Connection
Compressor model
ZB38/45KQ(E)
ZB48KQ(E)
A±3
437.7
443.4
B±3
409.6
413.7
A
B
233.21
296.70
19.1
12.7
Detail A
Scale 2:1
ø17.45 Pin Circle
Models: TFD, TFE, TFM, TF7
ø13.46 Pin Circle
Models: PFJ, PFV, TFW, TF5, PFZ
Terminal Box Layout Options
Terminal Box Cover Not Shown
View
A-A
Scale 3:2
245.6
245.6
122.8
122.8
190.5
190.5
95.3
95.3
115.2
69.2
242.1
250.4
125.3
31°
44°
Ø185.5
296.7 ±3.0
233.2
A
B
See Detail A
ø31.75 Thread
Rotalock Spud
Suction
ø25.4 Thread
Rotalock Spud
Discharge

Emerson ZB Copeland Scroll Specifications

General

Brand	Emerson
Model	ZB Copeland Scroll
Category	Compressor
Language	English
