Emerson ZB Copeland Scroll User Manual

52
ZB58 (BOM 523)
ZB Series
Dimensions Rotalock Connection
19.1
12.7
93.6
201.5
444.3
476.3
Detail FOOT
Scale 1:1
476.3
444.3
232.2
93.6
201.5
See Detail FOOT
(1.25-12) Thread Rotalock Spud
Discharge Check Valve
Torque Range 27.1-40.6 Newton-Meters
Steel Check Valve (240-360 in-Ibs)
(1.75-12) Thread Rotalock Spud
Suction Fitting
Torque Range 40.6-54.2
Newton-Meters
(360-480 in-Ibs)
242.5 MAX
242.5 MAX
121.3
190.5
190.5
95.3
95.3
157.8 159.3
71.9
142.3
124.6
121.3
30° 40°
4x Ø19.00-19.50
95.0
47.5
47.9
121.2
T-Box layout
Standard
Section A-A
Scale 1:1
ø17.45
Pin Circle
