Emerson ZB Copeland Scroll User Manual

60
ZB15
~
ZB29 (BOM 559)
ZB Series
Dimensions Rotalock & Sight Glass
A
B
C D
E
Ø165.9
Sight Glass/Socket Plug
Per Bill of Material
25.4 Thread
Rotalock Spud
Discharge Fitting
31.75 Thread
Rotalock Spud
Suction Fitting
242.1-248.1
237.9-243.9
121.5
190.5
95.3
95.3
107.2
64.4
239.0
227.8
190.5
116.7
40°
49°
31.0°
19.1
13.1
A
B
C D
E
ø17.45 Pin Circle
Models: TFD, TFE, TFM, TF7
ø13.46 Pin Circle
Models: PFJ, PFV, TFW, TF5, PFZ
Scale 2:1
See Detail
B
Detail B
Scale 2:1

Emerson ZB Copeland Scroll Specifications

General

Brand	Emerson
Model	ZB Copeland Scroll
Category	Compressor
Language	English
