Emerson ZB Copeland Scroll User Manual

61
ZB38
~
ZB48 (BOM 559)
ZB Series
Dimensions Rotalock & Sight Glass
245.6
245.6
122.8
122.8
190.5
190.5
95.3
95.3
115.2
69.2
242.1
250.4
125.3
31°
44°
132°
253.3-259.3
ø17.45 Pin Circle
Models: TFD, TFE, TFM, TF7
ø13.46 Pin Circle
Models: PFJ, PFV, TFW, TF5, PFZ
A
B C
233.21
296.70
19.1
12.7
Ø185.5
296.7 ±3.0
233.2
A
B
C
Sight Glass
Per Bill of Material
ø31.75 Thread
Rotalock Spud
Suction
ø25.4 Thread
Rotalock Spud
Discharge
Terminal Box Layout Options
Terminal Box Cover Not Shown
View
A-A
Scale 3:2
Detail
A
Scale 2:1
See Detail
A
