53
ZB66
~
ZB88 (BOM 523)
ZB Series
Dimensions Rotalock Connection
122.1 242.8 501.2 533.2
19.1
12.7
Detail FOOT
Scale 1:1
242.5 MAX
242.5 MAX
121.3
190.5
190.5
95.3
95.3
124.6
121.3
71.9 142.3
30°
40°
157.8
159.3
4x ø19.00-19.50
121.2
47.9
47.5
95.0
Section A-A
Scale 1:1
242.8
232.2
533.2
501.2
122.1
See Detail FOOT
(1.25-12) Thread Rotalock Spud
Discharge Check Valve
Torque Range 27.1-40.6 Newton-Meters
(240-360 in-Ibs)
(1.75-12) Thread Rotalock Spud
Suction Fitting
Torque Range 40.6-54.2
Newton-Meters
(360-480 in-Ibs)
