Emerson ZB Copeland Scroll User Manual

5
ZB15
~
ZB76
R134a
ZB15
~
ZB88
R404A/R507
ZB Series
Application Envelope
ZB95/ZB114
R404A/R507
60
70
50
40
30
20
10
Evaporating Temp.
o
C
Condensing Temp.
o
C
-20 -15 -10 -5 0 5 10 15
60
70
50
40
30
20
10
Evaporating Temp.
o
C
Condensing Temp.
o
C
-20 -15 -10 -5 0 5 10 15
R404A/R507 & R134a
Note:
1. Envelope In Non Shaded Region, max return gas temperature of 18.3°C
2. Envelope In Shaded Region, Max superheat of 11K only
Note:
1. Envelope In Non Shaded Region, max return gas temperature of 18.3°C
2. Envelope In Shaded Region, Max superheat of 11K only
Note:
1. Envelope In Non Shaded Region, max return gas temperature of 18.3°C
2. Envelope In Shaded Region, Max superheat of 11K only
60
80
70
50
40
30
20
10
Evaporating Temp.
o
C
Condensing Temp.
o
C
-20 -15 -10 -5 0 5 10 15
