EMI WLHG09 - Page 43

WLCG/WLHG High-Wall Air Handlers
• Installation, Operation and Maintenance Manual •
P/N 240008111, Rev. G [06/18/10] 43
Specifications and Dimensions (continued)
WLCG/WLHG electrical specificationsTable 5
MODEL VOLTS/HZ/PH
FAN
RLA
HP
HEATER
K.W.
AMPS
TOTAL
AMPS
MIN
VOLT
M.C.A.
HACR
BRKR
09–12
115/60/1 0.64 0.02 – – 0.64 104 0.8 15
208/230/60/1 0.34 0.02 – – 0.34 197 0.4 15
208/230/60/1 0.34 0.02 3 13.04 13.38 197 16.7 20
24
115/60/1 1.2 0.083 – – 1.2 104 1.5 15
208/230/60/1 0.56 0.07 – – 0.56 197 0.7 15
208/230/60/1 0.56 0.07 3 13.04 13.6 197 17 20
208/230/60/1 0.56 0.07 5 21.74 22.3 197 27.9 30
30/36
208/230/60/1 0.8 0.10 – – 0.8 197 1 15
208/230/60/1 0.8 0.10 5 21.74 22.54 197 28.2 30
NOTICE
Due to ongoing product development, designs, specications, and performance are
subject to change without notice. Please consult the factory for further information.
Discharge air speed and flow at 230VTable 7
Model
High speed
CFM (l/s)
Low speed
CFM (l/s)
Coil
FPM
(m/s)
Throw feet
(m)
Observed
sound values
(dBA)
WLHG
09–12
400 (190) 350 (170) Dry 900 (4.6) 15 (4.6) 45
WLHG24 750 (350) 675 (320) Dry 1,225 (6.2) 25 (7.5) 56
WLCG30 1,100 (520) 900 (420) Dry 1,250 (6.4) 27 (8.2) 60
WLCG36 1,100 (520) 900 (420) Dry 1,250 (6.4) 27 (8.2) 60
WLCG/WLHG interconnecting line sizesTable 6
Capacity Max.
Equivalent
Length
Max.
Lift
Max.
Trap
Height
Liquid
Line
Suction
Line
Condensate
Line
“H” “P” O.D. O.D. I.D.
9,000
50’
(15 m)
20’
(6 m)
15’
(5 m)
1/4" 1/2" 1/2"
12,000 1/4" 1/2" 1/2"
18,000*
100’
(30 m)
35’
(11 m)
20’
(6 m)
3/8" 5/8" * 1/2"
24,000 3/8" 3/4" 1/2"
30,000 3/8" 3/4" 1/2"
36,000 3/8" 3/4" 1/2"
* Must bush down to 5/8” interconnect for 18K system
