57
1. DESCRIZIONE DEI COMPONENTI
GBGB
5. UNIT POSITIONING
5.2 Minimum functional distances
ı1800
ı1500
ı1500
Dimension in mm
˚20
H
Ceiling
Wall
Wall
Floor
Model H (mm)
X-REVO-1219C 270
X-REVO-1819C 270
5.3 Dimensional data of the indoor unit
Air outlet
Air inlet
Air outlet
Gas Pipe
refrigerant
Liquid tube
refrigerant
Electric box
Display
Drainpipe
