24 Continuum User’s Manual
Large Muscle Trigger-Point — Summary (continued)
Preset Parameters Settings
Waveform Type SYM
Cycling Type SIM
Pulse Width 300 µs
Lag Delay 0 sec
CH 1 Up Time 2 sec
CH 1 On Time 10 sec
CH 1 Down Time 2 sec
CH 2 Up Time 2 sec
CH 2 On Time 10 sec
CH 2 Down Time 2 sec
Large Muscle Custom / Switch — Summary
This option offers similar stimulation as Large Muscle Spasm and Trigger-
Point if no external Foot Switch is detected.
Adjustable Parameters Range Default Setting
Treatment Time
5-60 min or Continuous 30 min
O Time 0-60 sec 30 sec
Pulse Rate 2 Hz-150 Hz 35 Hz
Pulse Width 48 µs-400 µs 300 µs
Waveform Type SYM, ASY SYM
Cycling Type SIM, 1 CH, ALT, LAG SIM
Lag Delay 0-5 sec 0 sec
CH 1 Ramp+ 0-5 sec 2 sec
CH 1 On Time 0-60 sec 10 sec
CH 1 Ramp– 0-5 sec 2 sec
CH 2 Ramp+ 0-5 sec 2 sec
CH 2 On Time 0-60 sec 10 sec
CH 2 Ramp– 0-5 sec 2 sec
If used with an external Switch, continuous stimulation is available for gait
training protocol. The intensity of each channel is independently adjustable.
Waveform, pulse width, and pulse rate parameters have default settings
and are the adjustable parameters (within range). Depending on the cycle
selected, all parameters may not be adjustable.
