26 Continuum User’s Manual
Small Muscle Spasm — Summary (continued)
Preset Parameters Settings
Waveform Type SYM
Cycling Type SIM
Pulse Width 300 µs
Lag Delay 0 sec
CH 1 Up Time 2 sec
CH 1 On Time 10 sec
CH 1 Down Time 2 sec
CH 2 Up Time 2 sec
CH 2 On Time 10 sec
CH 2 Down Time 2 sec
Small Muscle Trigger-Point — Summary
This treatment option is a 2-channel program for relaxation of muscles in
a localized area. All parameters are preset with the exception of Treatment
Time, Off Time and Pulse Rate which can be adjusted by the clinician. The
range of adjustments for Treatment Time, Off Time and Pulse Rate are listed in
the table below.
Adjustable Parameters Range Default Setting
Treatment Time 5-60 min or Continuous 30 min
O Time 0-60 sec 10 sec
Pulse Rate 2 Hz-150 Hz 50 Hz
Preset Parameters Setting
Waveform Type SYM
Cycling Type SIM
Pulse Duration 300 µs
Lag Delay 0 sec
CH 1 Up Time 3 sec
CH 1 On Time 10 sec
CH 1 Down Time 2 sec
CH 2 Up Time 3 sec
CH 2 On Time 10 sec
CH 2 Down Time 2 sec
