Page 48
0.3 Outputs
04. 07. 2015 09:17
RO1
HE control signal
Type
RO2
REL
Solar pump 1
TS4
Solar pump - Analog
---
---
TS1
TS2
TS3
0.4 Inputs
04. 07. 2015 09:18
59,6°C
Coll 1
45,8°C
---
52,8°C
0.4 Inputs
04. 07. 2015 09:19
TS3
TS4
---
52,8°C
---
---
Solar pump - Analog
The HE control signal is specied as: analogue
solar pump / PWM solar pump / analogue
heating pump / PWM heating pump / Wilo
ST25/7 PWM.
Once all outputs have been correctly as-
signed, acknowledge with „Continue“.
„0.4 Inputs“ appears.
Select and activate the input interfaces used
and assign the selected assignment by scroll-
ing. Inputs are specied as:
Coll 1 / Coll 2 / Tank 1 bot / Tank 2 bot /
Tank 3 bot / Tank 1 top / Tank 2 top / Tank 3
top / Incr return T. / tank return /
Swimming pool / Heat exch. / Bypass
COMMISSIONING MODE
Pre-assigned interfaces and their functions
are displayed.
